Electrical MaintenanceSeries Circuits

Series Circuits

0.27 Hrs
SKU: ELSERC0CEN

A circuit is a closed path through which electric current can flow. If there is more than one load in a circuit, there are two fundamentally different ways in which they can be connected. Loads can be connected in series or in parallel. In a series circuit, there is only one path for the current to flow through. All loads are connected end to end, forming a single continuous loop. A parallel circuit has multiple paths, or branches, through which current can flow.

This course provides an overview of series circuits and how to calculate current, voltage, and resistance using Ohm’s Law and Kirchhoff’s Voltage Law.

Get Training Now
Series Circuits
Get Training Now

Course Details

Learning Objectives

By the end of this course, you will be able to:

  • Define a series circuit.
  • Define Ohm’s Law and Kirchhoff’s laws related to current, voltage, and resistance.
  • Calculate total resistance in a series circuit.
  • Calculate total current in a series circuit.
  • State the relationship between current and voltage in a series circuit.
  • Calculate voltage drops across each resistor in a series circuit.

Specs

Course Level
Intermediate
Languages
English
Compatibility
Audio, Video, MobileReady, Responsive
