Steam Pipe Safety

0.50 Hrs
SKU: RVCT-521

Steam is used around the world in many different ways. In industrial environments, it is commonly used for power generation and in heating and drying applications. When used properly, steam is one of the cleanest, most efficient, and safest forms of energy in use. However, employees should be prepared and aware of the hazards present when working around steam pipes in order to avoid accidents and injuries. This course describes the hazards presented by steam pipes, how to prevent them, as well as how to properly inspect, insulate, and label steam pipes.

Course Details | FAQ | Transcript | Resources
Get Training Now
Steam Pipe Safety
Get Training Now

Course Details

Learning Objectives

• How steam is created • Hazards presented by hot steam pipes and associated equipment • Inspection of steam pipes, steam condensate pipes, steam vent pipes, lagging and valves • Steam pipe and valve insulation • Steam pipe labeling • Lockout/tagout • Proper Personal Protective Equipment • Responding to medical emergencies

Specs

Course Level
Intermediate
Languages
English
Compatibility
Audio, Video
Based on:
Industry Standards and Best Practices

Author | Vector Solutions

With over two decades of experience designing advanced 3D animated courseware and developing our proprietary learning management software, we pride ourselves by having developed over 1,000 safety and operations training modules, which have helped train over 250,000 workers worldwide. Our highly experienced team provides the industry with a simple and high-quality means of training their workforce. Whether your team consists of 25 people or an enterprise with thousands, we’re here to help.

Get Training Now

Frequently Asked Questions

How is steam created?

Steam is created when heat energy is added to liquid water, increasing the temperature to its boiling point. Once water has reached its boiling point, the temperature stops increasing, and that heat energy is now going towards creating vapor or “steam” rather than increasing the water’s temperature.

What are some safety guidelines to help prevent accidents?

Some safety guidelines that should be considered are: cleaning up wet floors immediately after a leak, or if a steam pipe is drained for maintenance, keep work areas clear of unneeded materials and equipment, avoid contact with steam, watch your head in areas with low headroom or projections, ventilate all spaces where work is taking place, and clean steam pipes regularly and keep them free from oil or grease.

Why and how should steam pipes be insulated?

Steam lines should be guarded and provide proper insulation to protect individuals from high temperatures as well as keep the system from losing heat. Steam lines should be insulated so that their temperature is less than the temperature which would result in a skin burn if touched. This is typically higher than 49 °C (120 °F), depending upon the length of contact.

What is water hammer?

“Water hammer” is the unexpected release of high pressure condensate that is then carried at high speeds in a steam pipe until it collides against a valve, or other component. When it impacts the inside of steam pipes, it causes a loud banging noise.

What are some common personal protective equipment that all personnel working near steam pipes should wear?

Personnel working near steam pipes should wear what’s required of them, which may include but isn’t limited to: coveralls (with heavily protected fabric, nonslip safety shoes with a hard toe cap, hearing protection, a face visor, impact- and chemical-resistant goggles, insulated leather gloves, and a respiratory device.

Sample Video Transcript

Steam pipes are labeled to identify their contents, as well as detail any specific hazards that exist. These specific hazards could include very hot temperatures or high pressures. If a pipe reads, “Steam 1.03 Bar” or “15 PSIG”, this specifies that the pipe contains steam at a pressure of 1.03 bar or 15 PSIG. Remember that any steam pipe over 1.03 bar or 15 PSIG, is classified as high pressure. An arrow is also typically shown along with the text label to show the direction that the steam flows. If steam could be flowing in either direction, arrows in both directions are displayed. Labels are positioned on the lower side of a pipe if the pipe is above eye level, directly facing you if the pipe is at eye level, or on the upper side of the pipe if the pipe is below eye level. Labels are normally located near valves, directional changes, or entry points, and evenly spaced on straight segments.

Additional Resources

  • U.S. Department of Labor’s Occupational Safety & Health Administration (OSHA) – www.osha.gov
  • OSHA grants – https://www.osha.gov/dte/grant_materials/fy07/sh-16634-07/mod_7_boiler_safety2.pptx
  • American Society for Testing and Materials (ASTM) – www.astm.org
  • American National Standards Institute – http://ansi.org
